Description

You are buying a tool that is used to air check the clutches and front or rear band in any 4L80E or 4L85E GM transmission.

  • The tool is made of aircraft grade 1/4″ thick aluminum
  • Comes with 27 grade 10.9 flange head bolts for years of trouble free service
  • It will NOT fit the Turbo 400 (non electronic) series – we have that plate also on our website.

It bolts down in place of the valve body and allows the transmission rebuilder to apply air pressure into the transmission once it’s assembled.  This is a good double check and an excellent way to diagnose internal leaks or damaged seals before installing the transmission.

Simply apply air to the holes provided and it will check the following internal components:

  • Forward Clutch
  • Intermediate Clutch
  • Over Run Clutch
  • Direct Clutch
  • Overdrive Clutch
  • Front Band Apply
  • Rear Band Apply
  • Reverse Boost valve / sleeve

Instructions and a pictorial that shows hole locations / functions is included.
